| -Voltage Rating | 170V |
| -Connector Style | BNC, HD |
| -Contact Termination | Crimp |
| -Product Training Modules | HD-BNC™ High-Density BNC |
| -Cable Group | Times Fiber 210 |
| -Center Contact Plating | Gold |
| -Body Finish | Nickel |
| -Fastening Type | Bayonet Lock |
| -Frequency - Max | 3GHz |
| -Dielectric Material | Polytetrafluoroethylene (PTFE) |
| -Online Catalog | BNC, HD |
| -Operating Temperature | -65°C ~ 165°C |
| -Impedance | 75 Ohm |
| -Shield Termination | Crimp |
| -Center Contact Material | Phosphor Bronze |
| -Body Material | Brass |
| -Other Related Documents | HD-BNC Assembly Instr |
| -Video File | Amphenol RF High Density BNC Connectors |
| -Mounting Type | Free Hanging (In-Line) |
| -Housing Color | Silver |
| -Standard Package | 1 |
| -Packaging | Bulk |
| -Family | Coaxial Connectors (RF) |
| -Connector Type | Plug, Male Pin |
