| -Current - Collector Pulsed (Icm) |
45A |
| -Power - Max |
133W |
| -IGBT Type |
Trench Field Stop |
| -Td (on/off) @ 25°C |
18ns/64ns |
| -Part Status |
Active |
| -Manufacturer |
Rohm Semiconductor |
| -Gate Charge |
32nC |
| -Family |
Transistors - IGBTs - Single |
| -Vce(on) (Max) @ Vge, Ic |
2.1V @ 15V, 15A |
| -Operating Temperature |
-40°C ~ 175°C (TJ) |
| -Moisture Sensitivity Level (MSL) |
1 (Unlimited) |
| -Package / Case |
TO-263-3, D²Pak (2 Leads + Tab), TO-263AB |
| -Test Condition |
400V, 15A, 10 Ohm, 15V |
| -Supplier Device Package |
LPDS (TO-263S) |
| -Current - Collector (Ic) (Max) |
30A |
| -Category |
Discrete Semiconductor Products |
| -Reverse Recovery Time (trr) |
55ns |
| -Voltage - Collector Emitter Breakdown (Max) |
650V |
| -Mounting Type |
Surface Mount |
| -Input Type |
Standard |
| -Lead Free Status / RoHS Status |
1 |
