Ameya360:Novosense automotive-qualified Integrated Absolute Pressure Sensor NSPAS1

Release time：2023-02-16

author：Ameya360

source：网络

reading：5603

　　NSPAS1 is a calibrated absolute pressure sensor launched by NOVOSENSE for vehicle intake pressure, NEV vacuum boosting system and motorcycle electronic injection. The product adopts automotive-qualified signal conditioning chip to calibrate and compensate the output of MEMS piezoresistive die, ensuring excellent reliability of the product while integrating the two chips to greatly reduce the package size.

At the same time, this product can provide standard output in its operation temperature range without customer calibration, which can accelerate the process of product development and mass production; the product complies with the AEC-Q100 reliability standard.

Ameya360:Novosense automotive-qualified Integrated Absolute Pressure Sensor NSPAS1

　　Product Features

　　Operating temperature range: -40℃~125℃

　　High accuracy in full temperature range:

　　Better than ±1%F.S. in the range of - 0℃~85℃

　　Better than ±1.5%F.S. in the range of -40℃~125℃

　　Support -24 v to 28V over voltage and reverse voltage protection

　　Fluorinated gel protection, compatible with oil and gas environment

　　Faster response time less than 0.8ms

　　Support absolute output/ratio-metric output, with output curve customized

　　Disconnection detection, output clamping, output alarm function

　　Pressure range 10kPa~400kPa, which can be customized

　　AEC-Q100 qualified

　　Package:SOP-8 (7.3mm x 7.3mm)

　　Application

　　Automotive: motorcycle three-in-one sensor, vehicle TMAP intake pressure detection, BPS battery pack thermal runaway pressure detection, EGR-TMAP exhaust gas recirculation pressure detection, canister desorption pressure detection, VBS vacuum boosting system sensor, ECU/VCU atmospheric pressure detection, seat air bag pressure detection

　　Industrial: pressure transmitter, industrial vacuum degree testing, etc.

　　Functional Block Diagram

Ameya360:Novosense automotive-qualified Integrated Absolute Pressure Sensor NSPAS1
